Data sheet

Product Feature

10 temperature sensors: 2 ambient sensors, 1 evaporator sensor, 1 condenser sensor, 6 drawer sensors. 8 relays to switch on loads: 1 compressor, 1 defrost (natural, resistance or hot gas), 1 fan, 1 lighting, 1 frequency inverter, 1 emergency system switch, 1 alarm, 1 redundancy system switch.

Four levels of access to settings, interface with graphic display and 7 keys, integration with Sitrad supervisory system, and datalogger support.

Power supply monitoring, temperature alarms simulation, emergency system battery charge monitoring, support for emergency system and auto dialing in critical situations.

The VC-108 Log is a temperature controller specially designed to ensure proper refrigeration of sensitive products like vaccines. It includes features such as backup system for power outages, redundant ambient temperature sensors, datalogger with over five years of storage, and support for the SitradPRO monitoring system. It also supports control redundancy and comes in a PCB format for direct integration into the refrigerator's mechanical structure.

USB port for exporting datalogger, importing and exporting presets, and updating the equipment. Maintenance time control included.

Weight

1.2 LBR

Model

VC-108 Log

UPC-EAN

NotAvailable

Sales Unit

EA

Origin

Brazil

US Tariff Code

9032.10.0090

Base Unit

EA
