Full Gauge MT-444E EasyCon Electronic Temperature Control 115-220 V, 50/60 Hz

The MT-444e EasyCon is a digital refrigeration controller designed to maximize power efficiency in commercial refrigeration systems. Featuring the EasyCon quick link connection system, it simplifies installation and boosts productivity in manufacturing lines. It offers three recipe options, each with its own control temperature (setpoint) and differentials (hysteresis) for precise system adjustments.

Additionally, it includes dedicated keys to activate economic mode, turn the lamp on/off, and enable fast freezing, optimizing energy consumption. Its digital filter delays the response time of the S1 ambient sensor, simulating an increased mass load to prevent unnecessary compressor activations, thereby improving efficiency and extending the compressor's lifespan.

For enhanced safety, the controller features an intelligent function blocking system and a control function shutdown mode, ensuring secure and efficient operation.

nbsp;

Technical specifications:

Connector for quick coupling

Fast Freezing

Power-saving mode

On/off light

Buzzer

Functions lock

Control functions shutdown

Serial Programming

Fron Protection IP65 level

nbsp;

Power supply:

nbsp;nbsp;nbsp;nbsp; MT-444E EasyCon: 115 or 230Vac plusmn;10% (50/60 Hz)

nbsp;nbsp;nbsp;nbsp; MT-444EL EasyCon: 12 or 24Vac/dc +10%

Approximate consumption: 3.4 VA

Setpoint Temperature: - 50 to 75deg;C (-58 to 167deg;F)

Operating Temperature: -10 to 50deg;C / 14 to 122deg;F

Operating humidity: 10 to 90% UR (without condensation)

Maximum current per output:

nbsp;nbsp;nbsp;nbsp; COMP: 12(8)A / 240Vac 1HP

nbsp;nbsp;nbsp;nbsp; DEFR: 3A / 240Vac 720W

nbsp;nbsp;nbsp;nbsp; FAN: 5(3)A / 240Vac

nbsp;nbsp;nbsp;nbsp; LIGHT: 5(3)A / 240Vac

Digital input: Dry contact type configurable

Maximum dimensions (in): 3 x 1.34 x 3.07 (WxHxD)

Cutouts dimensions (in):

nbsp;nbsp;nbsp;nbsp; X = 2.8 +/- 0,02

nbsp;nbsp;nbsp;nbsp; Y = 1.14 +/- 0,02
